WyreStorm Essentials 4K60 4×1 HDMI Switcher
$180.00
SKU: EXP-SW-0401-H2
The WyreStorm EXP-SW-0401-H2 is a powerful plug-and-play 4K switcher solution. With up to 18Gbps pure HDMI support, which allows up to four 4K HDR sources to be routed to a single display. The EXP-SW-0401-H2 is capable of auto switching, giving the user the convenience of simply turning on their favorite device without the requiring manual intervention. Furthermore, the EXP-SW-0401-H2 is equipped with signal compensation, allowing an extender or splitter to connect to its output without degrading or delaying the signal.
Inputs
4x HDMI In: 19-pin type A
Outputs
1x HDMI Out 19-pin HDMI type A
Video Encoding
HDMI | TMDS
Video Resolution (Max)
1920x1080p @60Hz 16bit
3840x2160p @60Hz 8bit 4:4:4 HDR
4096x2160p @60Hz 12bit 4:2:2 Dolby Vision/HDR10
Supported Standards
DCI | RGB | HDR | HDR10 | Dolby Vision | HLG | BT.2020 | BT.2100
Maximum Pixel Clock
600MHz
Color Depth
12bit
COMMUNICATION & CONTROL
HDMI
HDCP 2.2 | EDID | DVI-D supported with adapter (not included)
IR
1x IR Ext. Port
POWER
Power Supply
12V DC 1A
Max Power Consumption
3.2W
Features
- A true plug-and-play HDMI switcher, supporting up to four 4K HDR sources to one screen
- Compatible with the latest HDR standards, such as HDR10, HLG and Dolby Vision
- HDCP 2.2 compliant
- Automatic input cable equalization and signal regeneration eliminates signal degradation
- Slim design allows discrete placement, but sleek enough to show off in open spaces
